8 Channel 5V Relay Module MOD31, R11

DescriptionIt is a 5V 8 Channel Relay Module. The relay normally open interface maximum load: AC 250V/10A, DC 30V/10A. It has a trigger current of 5mA, and module working voltage of DC 5V. Each channel of the module can be triggered by a jumper to set a high level or a low level.Supply voltage – 3.75V to 6VTrigger current – 5mACurrent when relay is active – ~70mA (single), ~600mA (all eight)Relay maximum contact voltage – 250VAC, 30VDCRelay maximum current – 10AFeatures:A fixed bolt holes for easy installation.It has a relay status indicator led Power LED(Green), 8 relay status indicator LED(Red)Relay control interface by single-chip IO.Low-level suction close, high-level release.Easy to use, simple 3 line structure.Getting started with the 8 Channel 5V Relay ModuleArduino Relay Shield employs high quality relay with eight channels input and eight channels output. It can be connected to 250V/10A AC element or 24V/10A DC element to the maximum, therefore, it can be used to control lights, motors. The modularized design makes it easy to connect to Arduino expansion board. The output state of the relay is shown by a luminous diode for the convenience of actual application.Hardware requiredArduino UnoJumper wiresLed x38 Channel 5v Relay moduleConnecting the HardwareUpload the codeint BASE = 2 ; // I/O pin connected by the first relay int NUM = 8; //total number of all relays void setup() { for (int i = BASE; i < BASE NUM; i ) { pinMode(i, OUTPUT); //set digital I/O pin as output } } void loop() { for (int i = BASE; i < BASE NUM; i ) { digitalWrite(i, LOW); //set digital I/O pin as ‘low’, i.e. turning off the relay gradually delay(200); //delay } for (int i = BASE; i < BASE NUM; i ) { digitalWrite(i, HIGH); // set digital I/O pin as ‘low’， i.e. turning on the relay gradually delay(200); //delay } }
